Tesla Tool Matrix.
Interchangeable Die Sets and Locators.
| Picture | Tesla P/N | Rennsteig P/N | Description | Application | Capacity | Wire Type | Wire Size |
|---|---|---|---|---|---|---|---|
| Picture | Tesla P/N | Rennsteig P/N | Description | Application | Capacity | Wire Type | Wire Size |
 |
1631902-00-A | 624 1706 3 0 TSL | 1x Crimp Die Set | Staubli/Multi-Contact "MC4" PV-SP4/6, PV-BP4/6 |
12 AWG 4 SQ-MM |
 BETAflam
|
12 AWG |
|
Honglin |
|||||||
TESLA internal education material  |
View Instruction Manual |
View Datasheet |
|||||
Quality Crimping Guidelines (Visual Inspection)  |
|||||||
 |
1631901-00-A | 624 1706 0 01 TSL | 1x Locator for Die Set #624 1706 3 0 TSL |
Staubli/Multi-Contact "MC4" PV-SP4/6, PV-BP4/6 |
12 AWG 4 SQ-MM |
BETAflam 52 strands |
12 AWG |
|
Honglin |
|||||||
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
|||||
| Quality Crimping Guidelines (Visual Inspection) |
|||||||
 |
1811061-00-A | 624 1706 3 01 TSL | 1x Crimp Die Set 1x Locator |
Staubli/Multi-Contact "MC4" PV-SP4/6, PV-BP4/6 |
12 AWG 4 SQ-MM |
BETAflam 52 strands |
12 AWG |
|
Honglin |
|||||||
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
|||||
| Quality Crimping Guidelines (Visual Inspection) |
|||||||
 |
1631904-00-A | 624 1707 3 0 TSL | 1x Crimp Die Set | Staubli/Multi-Contact "MC4" PV-SP4/6, PV-BP4/6 |
10 AWG 6 SQ-MM |
 ADC19 strands |
10 AWG |
| Southwire E316464 2000V 19 strands |
|||||||
| Honglin E345972 19 strands | |||||||
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
|||||
| Quality Crimping Guidelines (Visual Inspection) |
|||||||
 |
1631903-00-A | 624 1707 0 01 TSL | 1x Locator for Die Set #624 1707 3 0 TSL |
Staubli/Multi-Contact "MC4" PV-SP4/6, PV-BP4/6 |
10 AWG 6 SQ-MM |
ADC 19 strands |
10 AWG |
| Southwire E316464 2000V 19 strands |
|||||||
| Honglin E345972 19 strands | |||||||
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
|||||
| Quality Crimping Guidelines (Visual Inspection) |
|||||||
 |
1811063-00-A | 624 1707 3 01 TSL | 1x Crimping Die Set for 1x Locator |
Staubli/Multi-Contact "MC4" PV-SP4/6, PV-BP4/6 |
10 AWG 6 SQ-MM |
ADC 19 strands |
10 AWG |
| Southwire E316464 2000V 19 strands |
|||||||
| Honglin E345972 19 strands | |||||||
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
|||||
| Quality Crimping Guidelines (Visual Inspection) |
|||||||
 |
1631906-00-A | 624 1708 3 0 TSL | 1x Crimp Die Set | Staubli/Multi-Contact "MC4" PV-SP4/6, PV-BP4/6 |
12 AWG 4 SQ-MM |
Encore 19 strands |
12 AWG |
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
|||||
| Quality Crimping Guidelines (Visual Inspection) |
|||||||
 |
1631905-00-A | 624 1708 0 01 TSL | 1x Locator for Die Set #624 1708 3 0 TSL |
Staubli/Multi-Contact "MC4" PV-SP4/6, PV-BP4/6 |
12 AWG 4 SQ-MM |
Encore 19 strands | |
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
|||||
| Quality Crimping Guidelines (Visual Inspection) |
|||||||
 |
1811065-00-A | 624 1708 3 01 TSL | 1x Crimping Die Set for 1x Locator |
Staubli/Multi-Contact "MC4" PV-SP4/6, PV-BP4/6 |
12 AWG 4 SQ-MM |
Encore 19 strands | |
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
|||||
| Quality Crimping Guidelines (Visual Inspection) |
|||||||
 |
1631907-00-A | 624 1711 3 0 TSL | 1x Crimp Die Set | Staubli/Multi-Contact "MC4" PV-SP4/6, PV-BP4/6 |
10 AWG 6 SQ-MM |
 Amphenol78 strands |
10 AWG |
| Byson 74 strands |
|||||||
| Wuxi 84 strands |
|||||||
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
|||||
| Quality Crimping Guidelines (Visual Inspection) |
|||||||
 |
1631909-00-A | 624 1711 0 01 TSL | 1x Locator for Die Set #624 1711 3 0 TSL |
Staubli/Multi-Contact "MC4" PV-SP4/6, PV-BP4/6 |
10 AWG 6 SQ-MM |
Amphenol 78 strands |
10 AWG |
| Byson 74 strands |
|||||||
| Wuxi 84 strands |
|||||||
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
|||||
| Quality Crimping Guidelines (Visual Inspection) |
|||||||
 |
1811066-00-A | 624 1711 3 01 TSL | 1x Crimping Die Set 1x Locator |
Staubli/Multi-Contact "MC4" PV-SP4/6, PV-BP4/6 |
10 AWG 6 SQ-MM |
Amphenol 78 strands |
10 AWG |
| Byson 74 strands |
|||||||
| Wuxi 84 strands |
|||||||
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
|||||
| Quality Crimping Guidelines (Visual Inspection) |
|||||||
 |
1631908-00-A | 624 1718 3 0 TSL | 1x Crimp Die Set | Staubli/Multi-Contact "MC4" barrel type PV-BP4/5 Sn, PV-SP4/5 Sn |
10 AWG 6 SQ-MM |
 ADC7 strands |
10 AWG |
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
|||||
 |
1631911-00-A | 624 1719 3 0 TSL | 1x Crimp Die Set | Staubli/Multi-Contact "MC4" barrel type PV-BP4/5 Sn, PV-SP4/5 Sn |
12 AWG 4 SQ-MM |
ADC 7 strands |
12 AWG |
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
|||||
 |
1631910-00-A | 624 1719 0 01 TSL | 1x Locator for Die Set #624 1718 3 0 TSL and #624 1719 3 0 TSL |
Staubli/Multi-Contact "MC4" barrel type PV-BP4/5 Sn, PV-SP4/5 Sn |
10 AWG 6 SQ-MM |
ADC 7 strands |
10 AWG |
| 12 AWG 4 SQ-MM |
ADC 7 strands |
12 AWG | |||||
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
|||||
 |
1811068-00-A | 624 1719 3 019 RT | 1x Crimping Die Set #624 1718 3 0 TSL 1x Crimping Die Set #624 1719 3 0 TSL 1x Locator for Die Set #1718 & #1719 |
Staubli/Multi-Contact "MC4" barrel type PV-BP4/5 Sn, PV-SP4/5 Sn |
10 AWG 6 SQ-MM |
ADC 7 strands |
10 AWG |
| 12 AWG 4 SQ-MM |
ADC 7 strands |
12 AWG | |||||
| TESLA internal education material |
View Instruction Manual |
View Datasheet |
Tools
| Picture | Tesla P/N | Rennsteig P/N | Description |
|---|---|---|---|
| Picture | Tesla P/N | Rennsteig P/N | Description |
 |
1640670-00-A | 624 000 3 TSL | Crimping Pliers PEW12 without Die Set |
| Instruction Manual |
|||
 |
1632289-00-A | 6370 0300 1 TSL | eForce (green) in case with US charger |
| Instruction Manual |
|||
 |
1632288-00-A | 700 016 36 TSL | Cable Cutter 15 with opening spring larger handles |
 |
1706081-00-A | 700 015 36 TSL | Cable Cutter 15 without opening spring larger handles |
 |
1640669-00-A | 6370 0300 1 TSL1 | eForce (black) in case with US charger |
| Instruction Manual |
|||
 |
1632286-00-A | RT1045 | Torque wrench / adjustable 3-6 Nm |
 |
TBD | 690 001 TSL | Set of 2 Rennsteig Assembly Keys for MC 4 connectors Comparable with MC PV-MS 32.6024 |
